    HMF 1030-K2 Specifications & Technical Data (2017-2021)

    Rate this machine now!

    The 1030-K2 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machin... Read more

    The 1030-K2 hydraulic loading crane model is manufactured by HMF. Find and download detailed specs and data sheets for this machine here.

    The HMF 1030-K2 can be grouped in the smallest machine segment in the hydraulic loading crane category. This model is 2.35m long and 0.747m wide. The 1030-K2 crane is equipped with a standard boom that is 7.5m long. The 1030-K2 Hydraulic Loading Crane has a maximum capacity of 2.52t. The load torque of this model is 95kNm.

    It does not include Remote control, High seat and Endless pivoting. Find detailed specifications and machine details in the original HMF 1030-K2 datasheet. Specification sheet is available for a free download in French, English, German and Spanish - providing the machine descriptions and more detailed specs about this particular model.

    Manufacturing of this model is still ongoing.

    At present, 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm are produced by HMF. Of these, 6020-K6 , 260-T2 and also 340-K2 are the most frequently visited on LECTURA Specs. Having been in production from 2017 to 2018, the 1030-K2 hydraulic loading crane ranks in the LECTURA index at #3380. Want more detailed specifications? Download the latest HMF 1030-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 1030-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 95 kNm
    • machine length 2.35 m
    • machine width 0.747 m
    • machine height 2.135 m
    • max. standard boom 7.5 m
    • Carrying capacity 1.27 t
    • at max. reach 7.5 m
    • Weight 1.09 t
    • max. carrying capacity 2.52 t
    • at reach 3.8 m
    • Required power 22 kW
    • Load of additional Jib ###
    • max. hook height ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
