365 6S Effer 365 6S Specifications & Technical Data (2017—2023)

The Effer 365 6S is a truck-mounted loading crane manufactured by Effer since 2017. It has a weight of 4.385 tons and a carrying c…

The Effer 365 6S is a truck-mounted loading crane manufactured by Effer since 2017. It has a weight of 4.385 tons and a carrying capacity of 1.45 tons. The load torque is 298 kNm, and the maximum carrying capacity is 11.9 tons. At its maximum reach of 16.95 meters, it can handle a load of 0.25 tons with the additional jib. The machine's standard boom extends up to 16.95 meters. The machine itself has a length of 6.4 meters, a width of 1.32 meters, and a height of 2.45 meters. At its maximum reach of 26.37 meters, it can handle a load at a reach of 2.36 meters.

Hydraulic loading cranes Effer 365 6S
Hydraulic loading cranes Effer 365 6S
Hydraulic loading cranes Effer 365 6S
Hydraulic loading cranes Effer 365 6S
Hydraulic loading cranes Effer 365 6S
Hydraulic loading cranes Effer 365 6S

Technical specs - 365 6S Effer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
298 kNm
machine length
6.4 m
machine width
1.32 m
machine height
2.45 m
max. standard boom
16.95 m
Carrying capacity
1.45 t
at max. reach
16.95 m
Load of additional Jib
0.25 t
Weight
4.385 t
max. carrying capacity
11.9 t
at reach
2.36 m

More technical details, like: max. hook height, required power, model series are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
No
Electronic load torque limitation
No
Endless pivoting
No
High seat
No
Remote control
No
Adjustable pivoting
No
Articulated boom overstraining
No
