D 25 WIDE 6X2 R LOW 320 E6 Renault (2013 - 2026) lorry truck specs & dimensions

Cab exterior

Day cab All steel Cab, electro-zinc plated and cataphoretic paint treatment. Cab paint colour: White ekla technical code: 09350 Red badge Anti-spray deflectors Four point mechanical cab suspension. Hydraulic cab tilt. 2 heated, remote control rear view mirrors. Rear view mirrors for bodywork up to 2.55 m wide Fold-back front view mirror Air horn Roof-level air intake. Air filter clogging indicator Spray suppression on front wings Tinted, laminated windscreen. Without rear window.

Suspension

Front suspension Front air suspension. Heavy duty stabiliser bar Rear suspension: Air suspension Suspension remote control (2 channels).

Options

Power mode inhibited after passing the 'hard spot' of the accelerator pedal Automatic engine cut-off (3 min) Automatic engine cut-off (5 min) Engine rear PTO: Splined hollow shaft output (DIN 5462). Continuous drive Rotation: as engine Max. torque: 600 Nm Ratio: 1/1 Position 12 o'clock Engine rear PTO: Output: ISO 7646 plate. Continuous drive

Packs

Pack "Fuel Eco Optiroll" comprising: Cruise Control with Optiroll with steering wheel-mounted controls Automatic engine cut-off (3 min) Gearshifting strategy optimised for FUEL ECO Power mode inhibited after passing the "hard spot" of the accelerator pedal Pack "Protect" comprising: Tyre pressure gauge Tyre inflation extension piece Cab volumetric alarm, immobilizer and load protection Passenger side vision door with lower tinted window Reversing warning buzzer, including night switch.

Fuel tank

Main steel tank. Main fuel tank: 255 litres capacity D560 profile mounted on right. Fuel heater in filter bowl.

Chassis

Chassis protective paintwork, mineral grey colour technical code: 03650. Chassis reinforcement at rear drive axle. Standard rear overhang, pre-drilled for bodybuilder. Removable front towing cap. Front under-run protection. Rear under-run bar. Closing cross member with pre-drilling for towing yoke. Lowered wing position, recommended for motorway use. Two wheel chocks with bracket. Side exhaust.

Bumper - steps and lighting

3-part plastic bumper. Access to driving position by 2 stepwell steps. Step lighting. Electrical headlamp levelling control. Running lights.

Bodywork

Body mounting brackets front and rear. Bodybuilder access through bulkhead. Orange LED side marker lights with reflector. Provision for bodybuilder electronic box interface.
