D 19 WIDE 4x2 R 320 E6 Renault (2020 - 2026) lorry truck specs & dimensions

Cab interior

Upper storage cupboard with net cover, 2 storage compartments (50 l) with net covers. Three sun blinds on windscreen. DTCO 4.0 digital chronotachograph. Air-suspended driver's seat with fitted seat belt. Driver's armrest. Red seat belts. Adjustable passenger seat. Blower socket on central console. Normal engine tunnel. Cab lighting time-delay. 2 coat hooks on rear panel. Electrically operated door windows. Air conditioning. Handbook and service pack in French.

Cab exterior

Day cab. All steel cab, electro-zinc plated and cataphoretic paint treatment. Cab paint colour: White, ekla technical code: 09350. Red badge. Anti-spray deflectors. Four point mechanical cab suspension. Hydraulic cab tilt. 2 heated, remote control rear view mirrors. Rear view mirrors for bodywork up to 2.55 m wide. Fold-back front view mirror.

Pack Comfort comprising

Manual roof vent. Multi-compartment storage on engine tunnel with 24 V socket. Second holder for smartphone. Upper storage cupboards with lids. Air-suspended COMFORT driver's seat, with lumbar support, heated seat base and seatback, seat depth adjustment and seat-mounted seat belt. Adjustable, 4-spoke leather steering wheel.

Gearbox

Optidriver AT 2412F gearbox (14.94 - 1) with automatic clutch. Aluminum housing. Max. torque 2400 Nm, 12 forwards gears and 3 reverse gears. Steering wheel-mounted operating mode selection (automatic/manual) via gear shift selector. Gearshifting strategy optimised for DISTRIBUTION.

Cruise Control with Optiroll

Cruise Control with Optiroll with steering wheel-mounted controls. Gearshifting strategy optimised for FUEL ECO. Power mode inhibited after passing the 'hard spot' of the accelerator pedal. Automatic engine cut-off (3 min). Adjustable roof deflector.

Minimum Front Axle Load

To maintain the driving comfort (lightness of steering, braking) of vehicles in all load and driving conditions once the vehicle is bodied, the following minimum front axle load(s) must be respected: 3500 kg. The weight of the vehicle is an average indicative weight of its STANDARD build, filled with urea, oil, windscreen wash liquid and coolant at 100%, fuel level at 90% and with driver (75kg).

Rear drive axle

P13170-E single reduction final drive axle without differential lock. Rear loading capacity (technical max.): 13 t. Drive axle ratio: 3.36.

Chassis

Chassis protective paintwork, mineral grey colour technical code: 03650. Standard rear overhang, pre-drilled for bodybuilder. Removable front towing cap, front under-run protection, and rear under-run bar. Closing cross member with pre-drilling for towing yoke. Wings fitted in standard position with side exhaust.

Bumper - Steps and Lighting

3-part plastic bumper. Access to driving position by 2 stepwell steps, step lighting, headlamp levelling control, and running lights.

Bodywork

Body mounting brackets front and rear. Bodybuilder access through bulkhead. Orange LED side marker lights with reflector and provision for bodybuilder electronic box interface.
