S 419 UL Setra (2019 - 2025) Bus Specs & Dimensions

Total length: 14980mm – Total width: 2550mm – Total height: 3240mm – Seats: 69 – Number of axles: 3 – Wheelbase front axle-drive a…

Total length: 14980mm – Total width: 2550mm – Total height: 3240mm – Seats: 69 – Number of axles: 3 – Wheelbase front axle-drive axle: 6920mm

All specifications of Setra S 419 UL Bus - dimensions: lenght, height, weight, number of seats, engine type and power and more - detailed S 419 UL vehicle specs.

Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL
Bus and Coaches Intercity buses Setra S 419 UL

Technical specs - S 419 UL Setra

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Total length
14980 mm
Total width
2550 mm
Total height
3240 mm
Seats
69
Number of axles
3
Wheelbase front axle-drive axle
6920 mm
Turning radius
11770 mm
Tank capacity
340 l
AdBlue additive tank
35 l
Engine type
OM 470
Engine Manufactor
Mercedes-Benz
Emission standard
Euro VI
Displacement
10.7 l
Engine power
290 kW
Max. torque
1900 Nm
Transmission
A
Model series
UL
