PC 1613 Shatal PC 1613 Specifications & Technical Data (2010—2014)

Weight: 112kg – Centrifugal force: 16kN – Working width: 460mm – Vibrating frequency: 93Hz – Power source: D – Model series: PC

Vibratory Plate Compactors Single Direction Vibratory Plate Compactors Shatal PC 1613

Technical specs - PC 1613 Shatal

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
112 kg
Centrifugal force
16 kN
Working width
460 mm
Vibrating frequency
93 Hz
Power source
D
Model series
PC
Engine manuf.
Hatz
Engine type
1B20
Engine power
3.4 kW
Displacement
0.232 l
Revolutions at max torque
3200 rpm

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Download datasheets (PDF)

Buy & Rent

Compare Shatal PC 1613 with similar Single Direction Vibratory Plate Compactors

Shatal PC 1613

Shatal PC 1613

Weight:
112 kg
Centrifugal force:
16 kN
Working width:
460 mm
Vibrating frequency:
93 Hz
Breaker BK 80-09

Breaker BK 80-09

Weight:
106 kg
Centrifugal force:
19 kN
Working width:
620 mm
Vibrating frequency:
96 Hz
Dynapac LX 90

Dynapac LX 90

Weight:
95 kg
Centrifugal force:
16 kN
Working width:
450 mm
Vibrating frequency:
75 Hz
Palme PTK15/45B

Palme PTK15/45B

Weight:
96 kg
Centrifugal force:
15 kN
Working width:
450 mm
Bomag BP 15/42 D-2 Y

Bomag BP 15/42 D-2 Y

Weight:
102 kg
Centrifugal force:
15 kN
Working width:
450 mm
Vibrating frequency:
90 Hz
