    Breaker BK 60-04 Specifications & Technical Data (2004-2015)

    Rate this machine now!

    Weight: 72kg – Centrifugal force: 9.7kN – Working width: 460mm – Vibrating frequency: 100Hz – Engine manuf.: Honda – Engine type: GX120

    Technical specs - BK 60-04 Breaker

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 72 kg
    • Centrifugal force 9.7 kN
    • Working width 460 mm
    • Vibrating frequency 100 Hz
    • Engine manuf. Honda
    • Engine type GX120
    • Engine power 3.6 kW

    More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Carbon footprint calculator for Single Direction Vibratory Plate Compactors

    Use the ERA equipment CO2 Calculator to find out the carbon footprint per hour of use of the Breaker BK 60-04 or alternative Single Direction Vibratory Plate Compactors.

    The carbon footprint calculation can be carried out using different biofuel scenarios or other factors.

    or go to the ERA Equipment CO2 Calculator to find out how to optimise your CO2 emissions.

    service provided by ERA

    Buy & Rent

    Compare Breaker BK 60-04 with similar Single Direction Vibratory Plate Compactors

    No image available

    Breaker BK 60-04

    Weight: 72 kg

    Centrifugal force: 9.7 kN

    Working width: 460 mm

    Vibrating frequency: 100 Hz

    Press 1 image
    Wacker WP 1540 AW

    Weight: 86 kg

    Centrifugal force: 15 kN

    Working width: 400 mm

    Vibrating frequency: 100 Hz

    Press 1 image
    weber mt CF 2

    Weight: 78 kg

    Centrifugal force: 12 kN

    Working width: 440 mm

    Vibrating frequency: 98 Hz

    Press 1 image
    Vibromax VMF 70

    Weight: 68 kg

    Centrifugal force: 13.4 kN

    Working width: 350 mm

    Vibrating frequency: 100 Hz

    Press 1 image
    PowerPac PPV 600

    Weight: 70 kg

    Centrifugal force: 7 kN

    Working width: 320 mm

    Vibrating frequency: 100 Hz
