G125RS JCB G125RS Specifications & Technical Data (2021—2026)
.jpg)
.jpg)
.jpg)
.jpg)
Visit JCB live at
Technical specs - G125RS JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal output
- 125 KVA
- Nominal current
- 150 A
- Nominal voltage
- 480 V
- Weight
- 3000 kg
- Transport length
- 3.2 m
- Transport width
- 1.09 m
- Transport height
- 2.11 m
- Model series
- RS
- Engine manuf.
- JCB
- Engine type
- N/A
- Engine power
- 100 kW
- Emission level
- Tier 4f
More technical details, like: type of cooling, carriage, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model
Special equipment
- Electric starter
-
No
- silenced
-
No
- Earth leakage monitor
-
No
- Automatic oil deficiency shutoff
-
No
- Thermo magnetic switch
-
No
- Ground fault circuit interrupter
-
No
