3032E John Deere 3032E Specifications & Technical Data (2008—2025)

Weight without attachment: 0.986t – Travel speed: 20km/h – Back tyres: 11.2-24 – Front tyres: 7.00-14 – Transport length: 2.81m – Transport width: 1.43m

Vehicles Compact Utility Tractors John Deere 3032E

Technical specs - 3032E John Deere

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight without attachment
0.986 t
Travel speed
20 km/h
Back tyres
11.2-24
Front tyres
7.00-14
Transport length
2.81 m
Transport width
1.43 m
Transport height
1.29 m
Model series
3
Engine manuf.
Yanmar
Engine type
3TNV86
Engine power
23.1 kW
Displacement
1.6 l
Revolutions at max torque
2400 rpm
Max. torque
108.5 Nm
No. of cylinders
3
Cylinder bore x stroke
89 x 90 mm

More technical details, like: transmission, bridge length, bridge width, steering mode, attachment, dimension lxwxh, weight, emission level are available in the full technical specs.

Special equipment

Cabin
No
Front hydraulics
No
Front PTO
No
All-wheel drive
No
Codriver seat
No
Rear hydraulic
No
Frontblade
No
Load tippable
No
Rear PTO
Yes
