TH522 Wacker Neuson Telehandler Specs & Dimensions (2014 - 2021)

The Wacker Neuson TH522 is a telehandler manufactured from 2014 to 2021. It has a weight of 4.2 tons and a transport length of 4.5…

The Wacker Neuson TH522 is a telehandler manufactured from 2014 to 2021. It has a weight of 4.2 tons and a transport length of 4.58 meters. The telehandler has a nominal load at COG of 2.2 tons and a lifting height of 5.06 meters. It can travel at a speed of 20 km/h and has a capacity of 2.2 tons at full lift height. The transport width is 1.81 meters and the transport height is 1.95 meters. The special equipment includes a quick hitch mechanism and a telescopic feature.

Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522
Telehandlers Wacker Neuson TH522

Visit Wacker Neuson live at

Technical specs - TH522 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
2.2 t
Standard tyres
10.5/80-18 MPT
Lifting height
5.06 m
Capacity at full lift height
2.2 t
Weight
4.2 t
Transport length
4.58 m
Transport width
1.81 m
Transport height
1.95 m
Travel speed
20 km/h
Engine manuf.
Perkins
Engine type
404D-22
Engine power
36.3 kW
Displacement
2.2 l
Revolutions at max torque
2800 rpm
No. of cylinders
4
Emission level
IIIA

More technical details, like: model series, centre of gravity, transmission type, max. reach horizontal, capacity at full forward reach, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load...

More technical details, like: model series, centre of gravity, transmission type, max. reach horizontal, capacity at full forward reach, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, max. torque, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, service brake - type, service brake - location, dimension configuration, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No
