MHT 780 T Manitou Telehandler Specs & Dimensions (2012 - 2016)

The Manitou MHT 780 T is a telehandler manufactured from 2012 to 2016. It has a weight of 12.8 tons and a transport length of 5.22…

The Manitou MHT 780 T is a telehandler manufactured from 2012 to 2016. It has a weight of 12.8 tons and a transport length of 5.225 meters. The maximum horizontal reach is 4 meters, and it can lift loads up to 8 tons at the nominal center of gravity. The lifting height is 6.8 meters, and it has a capacity of 2.75 tons at full forward reach. The center of gravity is located at 600 millimeters. It can also lift loads up to 8 tons at full lift height. The transport width is 2.44 meters, and the transport height is 2.52 meters.

Visit Manitou live at

Technical specs - MHT 780 T Manitou

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
8 t
Model series
MHT
Centre of gravity
600 mm
Transmission type
HY
Max. Reach horizontal
4 m
Capacity at full forward reach
2.75 t
Lifting height
6.8 m
Capacity at full lift height
8 t
Weight
12.8 t
Transport length
5.225 m
Transport width
2.44 m
Transport height
2.52 m
Engine manuf.
Perkins
Engine type
1104D-E44TA
Engine power
106 kW
No. of cylinders
4

More technical details, like: standard tyres, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement...

More technical details, like: standard tyres, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, attachment quickhitch, telematics available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, service brake - location, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No
