    Bobcat T 2250 Specifications & Technical Data (2007-2015)

    Rate this machine now!

    Bobcat is the manufacturer of the telehandler model T 2250. Find and download detailed specs and data sheets for this machine here... Read more

    Bobcat is the manufacturer of the telehandler model T 2250. Find and download detailed specs and data sheets for this machine here.

    The Bobcat T 2250 is a 4.56t machine with Kubota engine which powers this model with up to 56kW or 75 horse power. The Bobcat T 2250 can be grouped in the smallest machine segment in the telehandlers category. The measurements of the T 2250 are 1.84m x 4.145m x 2.185m. The size of standard tyres for this Bobcat T 2250 is 14x17.5. The Telehandler T 2250 Bobcat is designed to travel at a top speed of 25km/h. Max. Horizontal reach of this T 2250 model from Bobcat is 3,03m. It can lift 2.2t of nominal load with a 500mm centre of gravity. This telehandler from Bobcat is able to work with 2.2t capacity at up to 5.25m height. The capacity of this model at full forward reach is 1t.

    Diesel particulate filter, StVZO Equipment and Side displacement are not provided on this model as of 2015. There are more detailed specifications and machine descriptions available in the original Bobcat T 2250 specs data sheet. You can download it for free in Spanish, English, German, French, Dutch and Italian on LECTURA Specs.

    This model can be acquired for a list price between €55,000 and €70,000. Production of the T 2250 stopped in 2015. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    The T 2250 Bobcat can be compared to several models from other manufacturers. The closest telehandlers based on specification and pricing are the Massey Ferguson MF 9205, Manitou MLT 524 TMU and JCB 520-50. Bobcat currently produces 37 other telehandlers, which range from 2.6t up to 4.1t - the most visited on LECTURA Specs are T40180 IIIB, TL470HF Agri, TL470 Agri. Want more detailed specifications? Download the latest Bobcat T 2250 specs data sheet on LECTURA Specs today!

    Technical specs - T 2250 Bobcat

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Nominal load at COG 2.2 t
    • Standard tyres 14x17.5
    • Centre of gravity 500 mm
    • Transmission type HY
    • Max. Reach horizontal 3,03 m
    • Capacity at full forward reach 1 t
    • Lifting height 5.25 m
    • Capacity at full lift hight 2.2 t
    • Weight 4.56 t
    • Transport length 4.145 m
    • Transport width 1.84 m
    • Transport height 2.185 m
    • Travel speed 25 km/h
    • Engine manuf. Kubota
    • Engine type V3300
    • Engine power 56 kW
    • max. climbing ability ###
    • Dimension lxwxh ###
    • Displacement ###
    • Revolutions at max torque ###
    • Max. torque ###
    • No. of cylinders ###
    • Cylinder bore x stroke ###
    • Emission level ###
    • Cab Position ###
    • Chassis Type ###
    • Levelling - Chassis ###
    • Stabilisers ###
    • Drive - 2W / 4W ###
    • Transmission Type ###
    • Attachment Quickhitch ###
    • Telematics Available ###
    • Engine Manufacturer ###
    • Engine Model ###
    • Emission Rating ###
    • Aspiration ###
    • Rated Speed ###
    • Engine Output - Net ###
    • Torque ###
    • Tyre - Front Size ###
    • Tyre - Rear Size ###
    • Service Brake - Type ###
    • Service Brake - Location ###
    • Length - At Ground ###
    • Length - Front Of Carriage ###
    • Height - Over Cab ###
    • Width - Operating ###
    • Wheelbase ###
    • Ground Clearance ###
    • Width - Cab ###
    • Lift Height - Maximum ###
    • Reach - Maximum ###
    • Unstabilised Lift Height - With Maximum Capacity ###
    • Turning Radius - Over Tyres ###
    • Breakout Force ###
    • Lift Capacity - Maximum ###
    • Lift Capacity - To Max Height ###
    • Lift Capacity - To Max Reach ###
    • Unstabilised Lift Capacity - Maximum ###
    • Unstabilised Lift Capacity - To Max Height ###
    • Unstabilised Lift Capacity - To Max Reach ###
    • Fuel Tank ###
    • Number Of Boom Sections ###
    • Load Centre ###
    • Lift Capacity - Fork Maximum ###
    • Raise Time - Boom ###
    • Extend Time - Boom ###
    • Speed - Forward Maximum ###
    • Speed - Reverse Maximum ###
    • Operating Weight ###

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

    Special equipment

    • Diesel particulate filter
    • StVZO Equipment
    • Inclination correction
    • Side displacement
