    Baumann EX 35/12/40 Specifications & Technical Data (1997-2003)

    Rate this machine now!

    Nominal load at COG: 3.5t – Standard tyres: L2/Lx2 – Centre of gravity: 600mm – Drive system: G – Voltage: 80V – Traction motor: 2x7.5kW

    Technical specs - EX 35/12/40 Baumann

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Nominal load at COG 3.5 t
    • Standard tyres L2/Lx2
    • Centre of gravity 600 mm
    • Drive system G
    • Voltage 80 V
    • Traction motor 2x7.5 kW
    • Hoist motor 10 kW
    • Weight 5.5 t

    More technical details, like: construction height, total width, battery weight , lifting height, hoisting with / without load, lowering with load, travel speed with / without load, transmission type are available in the full technical specs.

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs without additional hydraulics, battery, charger. With Simplex mast (3,3m up to 10t • 5m > 10t load capacity). L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low-pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel

    Special equipment

    • Hydr. brace support
