Pegasus 45.30 Dieci Rotating Telehandler Specs & Dimensions (2017 - 2022)

Nominal load at COG: 4.5t – Centre of gravity: 600mm – Standard tyres: 18 R22.5 – Transmission type: HY – Max. Reach horizontal: 2…

Nominal load at COG: 4.5t – Centre of gravity: 600mm – Standard tyres: 18 R22.5 – Transmission type: HY – Max. Reach horizontal: 26.0m – Capacity at full forward reach: 0.2t

Rotating telehandler Pegasus 45.30 manufactured by Dieci, production years (2017 - 2022). Explore detailed Pegasus 45.30 360 degree telehandler specs: technical details, table charts and data sheets to download. Check also the other rotating telescopic forklift models produced by Dieci.

Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30
Rotating telehandlers Dieci Pegasus 45.30

Technical specs - Pegasus 45.30 Dieci

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
4.5 t
Centre of gravity
600 mm
Standard tyres
18 R22.5
Transmission type
HY
Max. Reach horizontal
26.0 m
Capacity at full forward reach
0.2 t
Lifting height
29.6 m
Capacity at full lift height
1.9 t
Weight
22.2 t
Transport length
8.4 m
Transport width
2.5 m
Transport height
3.1 m
Travel speed
40 km/h
max. climbing ability
40 %
Model series
Pegasus
Engine manuf.
FPT
Engine type
F4HFE413K*B015
Engine power
125 kW
Displacement
4.485 l
Revolutions at max torque
1500 rpm
Max. torque
710 Nm
No. of cylinders
4
Emission level
IV/Tier 4f

More technical details, like: dimension lxwxh, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, remote control system, telematics available, engine manufacturer, aspiration...

More technical details, like: dimension lxwxh, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, remote control system, telematics available, engine manufacturer, aspiration, engine output - net, engine output - gross, transmission control, steering type, service brake - type, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, width - stabiliser spread, lift height - maximum, lift height - with maximum capacity, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, carriage rotation angle, unstabilised lift height - with maximum capacity, stabilised lift height - with maximum capacity, turning radius - over tyres, turning radius - over forks, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, stabilised lift capacity - to max height, stabilised lift capacity - to max reach, fuel tank, diesel exhaust fluid, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
limited pivotable
No
endless rotation
Yes
