Kalmar DRG450-70C5X
- Nominal load at COG:
- 45 t
- Centre of gravity:
- 935 mm
- Standard tyres:
- 18 x 33". PR36. E4
- Max. Reach horizontal:
- 4.7 m
DRG450-70C5X Kalmar Reach Stacker Specs & Dimensions (2020 - 2026)
Technical specs - DRG450-70C5X Kalmar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 45 t
- Centre of gravity
- 935 mm
- Standard tyres
- 18 x 33". PR36. E4
- Max. Reach horizontal
- 4.7 m
- Weight
- 83.3 t
- Total width
- 4150 mm
- Construction height
- 4025 mm
- Lifting height
- 14.9 m
- Travel speed with / without load
- 28/18 km/h
- Turning radius
- 9.4 m
- Wheel base
- 7 m
- Model series
- DRG
- Engine manuf.
- Volvo
- Engine type
- TAD1182VE
- Engine power
- 285 kW
- Displacement
- 10.84 l
- Revolutions at max torque
- 1700 rpm
- Max. torque
- 1938/1300 Nm
- No. of cylinders
- 6
- Emission level
- EU V/EPA Tier 4f
More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications, prices and weight refer to basic models incl. spreader
