H1.5XT - AL Hyster LPG Forklift Specs & Dimensions (2022 - 2026)

Nominal load at COG: 1.5t – Centre of gravity: 500mm – Standard tyres: 6.0-9 (21x8-9)/5.0-8 – Weight: 2.64t – Total width: 1190mm …

Nominal load at COG: 1.5t – Centre of gravity: 500mm – Standard tyres: 6.0-9 (21x8-9)/5.0-8 – Weight: 2.64t – Total width: 1190mm – Construction height: 2160mm

Hyster is the manufacturer of the H1.5XT - AL LPG forklift. The production years for this model are (2022 - 2026). Find here detailed specs for H1.5XT - AL LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Hyster.

LPG Forklifts Hyster H1.5XT - AL

Technical specs - H1.5XT - AL Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1.5 t
Centre of gravity
500 mm
Standard tyres
6.0-9 (21x8-9)/5.0-8
Weight
2.64 t
Total width
1190 mm
Construction height
2160 mm
Turning radius
6.025 m
Lifting height
3.035 m
Travel speed with / without load
18/19 km/h
Hoisting with / without load
0.625/0.68 m/s
Lowering with load
0.52 m/s
max. climbing ability
37 %
Model series
H
Engine manuf.
GCT
Engine type
K21
Engine power
31 kW
Displacement
2.065 l
Revolutions at max torque
1600 rpm
Max. torque
144 Nm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Hyster H1.5XT - AL overview

Hyster H1.5XT - AL features overview

Counterweight

The superior design channels a significant increase in airflow to optimise cooling, even in extreme temperatures and environments.


Drive

Swing Down Gas Tank

The swing down gas tank bracket allows for simple, quick exchange of the LPG tank and saves operator strain.


Hydrostatic Steer Axle

Maximum durability, increased steer angle and steering control for easy manoeuvring and lower maintenance. New steer knob synchroniser system returns the steer knob to the same position when travelling in a straight line – improves operator comfort and control.


Safety

Hyster® Stability Mechanism™

The patented stability system reduces truck sway during turns, improving lateral stability. This innovative design allows for confident travel over uneven surfaces.


Cabin & Equipment

Operator Compartment

Ergonomically designed, fatigue reducing operator compartment enhances overall productivity. Features include: easy access step, generous foot space, fully adjustable seat and steering wheel, well positioned foot pedals, insulated engine cover and optional seatside Mini Levers.


Engine Cover

The tough steel engine cover is hinged at the rear, offering excellent service access to the engine compartment.
