HT120Ds/600 Linde Diesel Explosion Proof Forklift Specs & Dimensions (2017 - 2025)

Nominal load at COG: 12t – Centre of gravity: 600mm – Standard tyres: 4x/2 – Transmission type: HY – Weight: 16t – Total width: 25…

Nominal load at COG: 12t – Centre of gravity: 600mm – Standard tyres: 4x/2 – Transmission type: HY – Weight: 16t – Total width: 2530mm

HT120Ds/600 diesel powered explosion proof forklift model manufactured by Linde in (2017 - 2025). Explore detailed HT120Ds/600 diesel explosion protected lift truck specs: technical details, table charts and data sheets to download. Check also the other models produced by Linde.

Technical specs - HT120Ds/600 Linde

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
12 t
Centre of gravity
600 mm
Standard tyres
4x/2
Transmission type
HY
Weight
16 t
Total width
2530 mm
Construction height
3404 mm
Lifting height
4 m
Turning radius
4 m
Travel speed with / without load
27.6/29.1 km/h
Hoisting with / without load
0.4/0.42 m/s
Lowering with load
0.45 m/s
max. climbing ability
79.7 %
Model series
1411
Engine manuf.
MTU
Engine type
4R1000 C30
Engine power
129 kW
Displacement
5.1 l
Revolutions at max torque
2200 rpm
No. of cylinders
4

More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Linde HT120Ds/600 overview

Handling

Safety

The driver’s all-round visibility is achieved by the unique design of the new HT100Ds-HT180Ds. By positioning the cab, seat and steering wheel in the centre of the truck, the driver is able to see both the load and the surrounding area. The cab’s fully adjustable armrest and steering wheel ensure that every driver can find the ideal driving position. The cab is also equipped with a large “Panoramic View” roof. The Linde Protector Frame protects the driver and load, and consequently the driver is able to work tirelessly and without fatigue.


Performance

The handling of all HT100Ds-HT180Ds range is the top priority. The new standard cab with hydraulic engine cover and the new hydraulic system, the truck uses every drop of maximum power to ensure the best possible performance. The new Linde Load Control system allows the driver to control all mast functions with precision and ease. Night visibility is also ensured by the robust, standard mast lights.


Productivity

Newly developed and proven load handling and drive control features increase productivity and reduce overall production time. The new Linde Load Control system allows the driver to control all mast functions with precision and ease. The new Linde Hydrostatic Drive system provides a smooth and precise power delivery, allowing the driver to work more efficiently and effectively.
