    Yale GP155SVX Specifications & Technical Data (2021-2021)

    Rate this machine now!

    Nominal load at COG: 7t – Standard tyres: Front: 8.25 X 15 14PR / Rear: 8.25 X 15 14PR – Centre of gravity: 610mm – Weight: 10.24t – Total width: 2082mm – Construction height: 2456mm

    Technical specs - GP155SVX Yale

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Nominal load at COG 7 t
    Standard tyres Front: 8.25 X 15 14PR / Rear: 8.25 X 15 14PR
    Centre of gravity 610 mm
    Weight 10.24 t
    Total width 2082 mm
    Construction height 2456 mm
    Turning radius 3.08 m
    Lifting height 3 m
    Travel speed with / without load 20,3/21,6 km/h
    Hoisting with / without load 0,46/0,52 m/s
    Lowering with load 0.58 m/s
    max. climbing ability 32/25 %
    Engine manuf. Kubota
    Engine type 3.8L DOC
    Engine power 55 kW
    Engine power 74 HP
    Displacement 3.8 l
    Revolutions at max torque 1400 rpm
    Max. torque 309 Nm
    No. of cylinders 4
    Transmission type ###
    Dimension lxwxh ###
    Cylinder bore x stroke ###
    Weight ###
    Emission level ###

    L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
