GDP 80 DB Yale diesel forklift specs & dimensions (2006 - 2009)
.jpg)
.jpg)
Visit Yale live at
Technical specs - GDP 80 DB Yale
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 8 t
- Centre of gravity
- 600 mm
- Standard tyres
- 4x/2
- Transmission type
- W
- Weight
- 12.378 t
- Total width
- 2425 mm
- Construction height
- 3015 mm
- Turning radius
- 3.996 m
- Lifting height
- 5.336 m
- Travel speed with / without load
- 26.43/28.09 km/h
- Hoisting with / without load
- 0.46/0.74 m/s
- Lowering with load
- 0.54/0.49 m/s
- max. climbing ability
- 32 %
- Model series
- GDP
- Engine manuf.
- Cummins
- Engine type
- QSB6.7
- Engine power
- 117 kW
- Displacement
- 6.7 l
- Revolutions at max torque
- 2150 rpm
- Max. torque
- 673/1500 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 107x124 mm
- Emission level
- IV
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
Download datasheets (PDF)
