RCD 160/600 Still diesel forklift specs & dimensions (2022 - 2026)

The Still RCD 160/600 is a diesel forklift manufactured since 2022. It has a weight of 19.72 tons and a nominal load at the center…

The Still RCD 160/600 is a diesel forklift manufactured since 2022. It has a weight of 19.72 tons and a nominal load at the center of gravity of 16 tons. The lifting height reaches up to 4 meters, with a center of gravity at 600 mm. The lowering speed with load is 0.45 m/s. The total width of the forklift is 2565 mm, and it has a turning radius of 4.34 meters. The construction height is 3736 mm.

Technical specs - RCD 160/600 Still

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
16 t
Centre of gravity
600 mm
Standard tyres
L 4x/2
Transmission type
W
Weight
19.72 t
Total width
2565 mm
Construction height
3736 mm
Turning radius
4.34 m
Lifting height
4 m
Travel speed with / without load
28.1/30.1 km/h
Hoisting with / without load
0.37/0.42 m/s
Lowering with load
0.45 m/s
max. climbing ability
65.3 %
Model series
RCD
Engine manuf.
Mercedes-Benz
Engine type
OM934
Engine power
150 kW
Displacement
5.1 l
Revolutions at max torque
2200 rpm
No. of cylinders
4
Emission level
V

More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Still RCD 160/600 overview

Still RCD 160/600 features overview

Heavy-Duty Forklift Truck

Loads weighing up to 18 tonnes? Bulky goods? Tough operating conditions? The STILL RCD 100-180 heavy-duty forklift truck does the job for you! Its efficient and powerful common-rail turbo engines provide enough power to satisfy even the greatest handling appetite quickly and effectively. How much fuel does your new heavyweight champion consume in the process? Less! The results of the tested comparative work cycles show that the RCD 100-180 consumes less than all other torque converters. You don’t have to worry about the EU emission standard either: The STILL RCD 100-180 is well below the currently required limit values. It boasts impressive handling power and extremely intuitive and sensitive controls: Thanks to the precise hydraulics and excellent visibility, your employees can get the best possible performance out of the truck in any situation. In the event that the view to the front is blocked by large loads, the entire driver’s workspace, including the control elements, can be rotated by 180 degrees. Regardless of the load you have to move, the wide range of fork carriages and attachments of the RCD 100-180 will take the weight off your shoulders.


Safety

Truck Features

Powerful and economical: exceptional handling performance meets the lowest levels of consumption of all hydrodynamically driven trucks in its class. Stable all-round visibility: visibility-optimised truck design with sloped counterweight and armoured glass roof window. Ergonomically excellent: roomy and low-vibration workstation, decoupled, with easy to use control units.
