FD10 OCTANE diesel forklift specs & dimensions (2024 - 2026)

Nominal load at COG: 1t – Centre of gravity: 500mm – Standard tyres: F: 6.50-10-10PR / R: 5.00-8-10PR – Weight: 2.49t – Total widt…

Nominal load at COG: 1t – Centre of gravity: 500mm – Standard tyres: F: 6.50-10-10PR / R: 5.00-8-10PR – Weight: 2.49t – Total width: 1087mm – Construction height: 2040mm

OCTANE is the manufacturer of the FD10 diesel forklift. The production years for this model are (2024 - 2026). Find here detailed specs for FD10 diesel powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by OCTANE.

Diesel Forklifts OCTANE FD10

Technical specs - FD10 OCTANE

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
1 t
Centre of gravity
500 mm
Standard tyres
F: 6.50-10-10PR / R: 5.00-8-10PR
Weight
2.49 t
Total width
1087 mm
Construction height
2040 mm
Turning radius
1.98 m
Lifting height
3 m
Travel speed with / without load
15 km/h
Hoisting with / without load
0.46 m/s
max. climbing ability
20 %
Model series
FD
Engine manuf.
Mitsubishi
Engine type
D04EG
Engine power
26.8 kW
Displacement
1.86 l
Revolutions at max torque
1800 rpm
Max. torque
177 Nm
No. of cylinders
4
Cylinder bore x stroke
88x102 mm

More technical details, like: transmission type, lowering with load, dimension lxwxh, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
