FD30N3 Mitsubishi FD30N3 diesel forklift specs & dimensions (2020 - 2026)

Name: Mitsubishi FD30N3 Diesel Forklifts
Brand: Mitsubishi

The Mitsubishi FD30N3 is a diesel forklift machine manufactured since 2020. It has a weight of 4.43 tons and a nominal load capaci…

The Mitsubishi FD30N3 is a diesel forklift machine manufactured since 2020. It has a weight of 4.43 tons and a nominal load capacity of 3 tons at the center of gravity. The lifting height of this forklift is 3.27 meters, with a center of gravity at 500 millimeters. It has a maximum climbing ability of 39 percent and a lowering speed of 0.5 meters per second with a load. The total width of the forklift is 1690 millimeters, and it has a turning radius of 2.38 meters. The construction height of the machine is 2170 millimeters.

FD30N3

Years of manufacture: 2020—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - FD30N3 Mitsubishi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3 t

Centre of gravity: 500 mm

Standard tyres: SE 2x/2

Transmission type: W

Weight: 4.43 t

Total width: 1275 mm

Construction height: 2165 mm

Turning radius: 2.38 m

Lifting height: 3.3 m

Travel speed with / without load: 16/17 km/h

Hoisting with / without load: 0,49/0,51 m/s

Lowering with load: 0.50/0.50 m/s

max. climbing ability: 39 %

Model series: Grendia ES

Engine manuf.: k.A.

Engine type: D04EG

Engine power: 36 kW

Displacement: 3.331 l

Revolutions at max torque: 2250 rpm

Max. torque: 177/1800 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
