FD 55 N Mitsubishi diesel forklift specs & dimensions (2010 - 2015)

Name: Mitsubishi FD 55 N Diesel Forklifts
Brand: Mitsubishi

The Mitsubishi FD 55 N is a diesel forklift manufactured by Mitsubishi from 2010 to 2015. It has a weight of 7.6 tons and a nomina…

The Mitsubishi FD 55 N is a diesel forklift manufactured by Mitsubishi from 2010 to 2015. It has a weight of 7.6 tons and a nominal load at the center of gravity of 5.5 tons. The lifting height reaches up to 5.5 meters, with a center of gravity at 600 mm. It has a maximum climbing ability of 19 percent. The total width of the forklift is 1965 mm, and it has a turning radius of 2.94 meters. The construction height is 2400 mm.

FD 55 N

Years of manufacture: 2010—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

See offers

Technical specs - FD 55 N Mitsubishi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 5.5 t

Centre of gravity: 600 mm

Standard tyres: SE 2x/6

Transmission type: W

Weight: 7.6 t

Total width: 1965 mm

Construction height: 2400 mm

Turning radius: 2.94 m

Lifting height: 5.5 m

Travel speed with / without load: 19/25 km/h

Hoisting with / without load: 0.47/0.53 m/s

Lowering with load: 0.5 m/s

max. climbing ability: 19 %

Model series: FD

Engine manuf.: Mitsubishi

Engine type: S6S

Engine power: 57 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
