Maximal FD 70 T-MWF3
- Nominal load at COG:
- 7 t
- Centre of gravity:
- 600 mm
- Standard tyres:
- 8.50-15-14PR
- Weight:
- 9.45 t
FD 70 T-MWF3 Maximal diesel forklift specs & dimensions (2010 - 2016)
Technical specs - FD 70 T-MWF3 Maximal
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Nominal load at COG
- 7 t
- Centre of gravity
- 600 mm
- Standard tyres
- 8.50-15-14PR
- Weight
- 9.45 t
- Total width
- 1995 mm
- Construction height
- 2625 mm
- Turning radius
- 3.37 m
- Lifting height
- 3 m
- Travel speed with / without load
- 26/28 km/h
- Hoisting with / without load
- 0.38/0.42 m/s
- Lowering with load
- 0.5 m/s
- max. climbing ability
- 30 %
- Model series
- M
- Engine manuf.
- Isuzu
- Engine type
- 6 BG 1
- Engine power
- 82 kW
More technical details, like: transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
