FD 200 TX-MWK3 Maximal diesel forklift specs & dimensions (2010 - 2016)

The Maximal FD 200 TX-MWK3 is a diesel forklift manufactured from 2010 to 2016. It has a weight of 26 tons and a nominal load at t…

The Maximal FD 200 TX-MWK3 is a diesel forklift manufactured from 2010 to 2016. It has a weight of 26 tons and a nominal load at the center of gravity of 20 tons. The lifting height reaches up to 3 meters, with a center of gravity at 900 mm. It has a maximum climbing ability of 25 percent. The total width of the forklift is 2535 mm, and it can travel at a speed of 30 km/h with or without load. The turning radius is 5.2 meters, and the construction height is 3420 mm.

Maximal FD 200 TX-MWK3 Dimensions and Size

Technical specs - FD 200 TX-MWK3 Maximal

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
20 t
Centre of gravity
900 mm
Weight
26 t
Total width
2535 mm
Construction height
3420 mm
Turning radius
5.2 m
Lifting height
3 m
Travel speed with / without load
30 km/h
Hoisting with / without load
0.32 m/s
Lowering with load
0.38 m/s
max. climbing ability
25 %
Model series
M
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
142 kW

More technical details, like: standard tyres, transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
