FD 100 T-MWL3 Maximal diesel forklift specs & dimensions (2010 - 2016)

The Maximal FD 100 T-MWL3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 12.56 tons and a nomi…

The Maximal FD 100 T-MWL3 is a diesel forklift manufactured by Maximal from 2010 to 2016. It has a weight of 12.56 tons and a nominal load at the center of gravity of 10 tons. The forklift can lift loads up to a height of 3 meters and has a center of gravity at 600 mm. It has a maximum climbing ability of 20 percent and a total width of 2248 mm. The turning radius of the forklift is 3.9 meters and it has a construction height of 2850 mm.

Diesel Forklifts Maximal FD 100 T-MWL3
Maximal FD 100 T-MWL3 Dimensions and Size
Diesel Forklifts Maximal FD 100 T-MWL3
Maximal FD 100 T-MWL3 Dimensions and Size

Technical specs - FD 100 T-MWL3 Maximal

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
10 t
Centre of gravity
600 mm
Standard tyres
9.00-20-14PR
Weight
12.56 t
Total width
2248 mm
Construction height
2850 mm
Turning radius
3.9 m
Lifting height
3 m
Travel speed with / without load
26/28 km/h
Hoisting with / without load
0.31 m/s
Lowering with load
0.4 m/s
max. climbing ability
20 %
Model series
M
Engine manuf.
Cummins
Engine type
QSB4.5-C110
Engine power
80.9 kW
Emission level
EU III

More technical details, like: transmission type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
