H18D Linde diesel forklift specs & dimensions (2006 - 2019)

Name: Linde H18D Diesel Forklifts
Brand: Linde

The Linde H18D is a diesel forklift manufactured by Linde from 2006 to 2019. It has a weight of 2.91 tons and a nominal load at th…

The Linde H18D is a diesel forklift manufactured by Linde from 2006 to 2019. It has a weight of 2.91 tons and a nominal load at the center of gravity of 1.8 tons. The forklift can lift loads up to a height of 5 meters, with a center of gravity at 500 mm. It has a maximum climbing ability of 36 percent and a lowering speed of 0.57 meters per second with a load. The total width of the forklift is 1086 mm, and it can travel at a speed of 20 km/h with or without a load. The turning radius is 2 meters, and the construction height is 2123 mm.

H18D

Years of manufacture: 2006—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - H18D Linde

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 1.8 t

Centre of gravity: 500 mm

Standard tyres: SE4x

Transmission type: HY

Weight: 2.91 t

Total width: 1086 mm

Construction height: 2123 mm

Turning radius: 2 m

Lifting height: 5 m

Travel speed with / without load: 20 km/h

Hoisting with / without load: 0.6/0.63 m/s

Lowering with load: 0.57 m/s

max. climbing ability: 36 %

Model series: 391

Engine manuf.: VW

Engine type: BXT

Engine power: 26 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
