70 D 7 E Hyundai diesel forklift specs & dimensions (2011 - 2019)

The Hyundai 70 D 7 E is a diesel forklift manufactured by Hyundai from 2011 to 2019. It has a weight of 9.871 tons and a nominal l…

The Hyundai 70 D 7 E is a diesel forklift manufactured by Hyundai from 2011 to 2019. It has a weight of 9.871 tons and a nominal load at the center of gravity of 7 tons. The lifting height of this forklift is 3.03 meters, with a center of gravity at 600 millimeters. It has a maximum climbing ability of 37.2 percent. The total width of the forklift is 2268 millimeters. It can travel at a speed of 34.8 kilometers per hour with or without a load. The turning radius of this forklift is 3.36 meters, and its construction height is 2500 millimeters.

Diesel Forklifts Hyundai 70 D 7 E

Visit Hyundai live at

Technical specs - 70 D 7 E Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
7 t
Centre of gravity
600 mm
Standard tyres
L 4x/2
Transmission type
W
Weight
9.871 t
Total width
2268 mm
Construction height
2500 mm
Turning radius
3.36 m
Lifting height
3.03 m
Travel speed with / without load
34.8 km/h
Hoisting with / without load
0.42/0.46 m/s
Lowering with load
0.5/0.45 m/s
max. climbing ability
37.2 %
Model series
7
Engine manuf.
Hyundai
Engine type
D 4 DD
Engine power
73.5 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
