    Lectura specs Forklifts Diesel Forklifts Diesel Forklifts Hyundai Hyundai 250 D 7 E specifications

    Technical specs - 250 D 7 E Hyundai

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Nominal load at COG 25 t
    Standard tyres L 4x/2
    Centre of gravity 1200 mm
    Transmission type W
    Weight 37.021 t
    Total width 3050 mm
    Construction height 3223 mm
    Turning radius 5.807 m
    Lifting height 4.03 m
    Travel speed with / without load 31.7 km/h
    Hoisting with / without load 0.25/0.28 m/s
    Lowering with load 0.4/0.3 m/s
    max. climbing ability 33.8 %
    Engine manuf. Cummins
    Engine type QSC25
    Engine power 194 kW
    Engine power ###
    Dimension lxwxh ###
    Displacement ###
    Revolutions at max torque ###
    Max. torque ###
    No. of cylinders ###
    Cylinder bore x stroke ###
    Weight ###
    Emission level ###

    L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
