H8XM EC6 Hyster diesel forklift specs & dimensions (2016 - 2019)

Name: Hyster H8XM EC6 Diesel Forklifts
Brand: Hyster

The Hyster H8XM EC6 is a diesel forklift manufactured by Hyster from 2016 to 2019. It has a weight of 13.385 tons and a nominal lo…

The Hyster H8XM EC6 is a diesel forklift manufactured by Hyster from 2016 to 2019. It has a weight of 13.385 tons and a nominal load at the center of gravity of 8 tons. The forklift has a lifting height of 5.336 meters and a center of gravity at 600 millimeters. It has a maximum climbing ability of 52 percent and a total width of 2419 millimeters. The turning radius of the forklift is 3.926 meters and the construction height is 3033 millimeters.

H8XM EC6

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - H8XM EC6 Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 8 t

Centre of gravity: 600 mm

Standard tyres: L 4x/2

Transmission type: W

Weight: 13.385 t

Total width: 2419 mm

Construction height: 3033 mm

Turning radius: 3.926 m

Lifting height: 5.336 m

Travel speed with / without load: 30.1/30.6 km/h

Hoisting with / without load: 0.54/0.59 m/s

Lowering with load: 0.5/0.48 m/s

max. climbing ability: 52 %

Model series: H

Engine manuf.: Cummins

Engine type: QSB4.5

Engine power: 119 kW

Displacement: 4.5 l

Revolutions at max torque: 2300 rpm

Emission level: IV

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

H8XM EC6 Hyster Specification for Europe (EN)
