H5.0FT Hyster diesel forklift specs & dimensions (2005 - 2019)

The Hyster H5.0FT is a diesel forklift manufactured by Hyster from 2005 to 2019. It has a weight of 7.523 tons and a nominal load …

The Hyster H5.0FT is a diesel forklift manufactured by Hyster from 2005 to 2019. It has a weight of 7.523 tons and a nominal load capacity of 5 tons at the center of gravity. The forklift can lift loads up to a height of 4.145 meters and has a center of gravity at 600 mm. It has a maximum climbing ability of 21.5 percent and a total width of 1450 mm. The turning radius of the forklift is 2.877 meters, and its construction height is 2300 mm.

Diesel Forklifts Hyster H5.0FT
Diesel Forklifts Hyster H5.0FT
Hyster H5.0FT Dimensions and Size
Diesel Forklifts Hyster H5.0FT
Diesel Forklifts Hyster H5.0FT
Hyster H5.0FT Dimensions and Size

Technical specs - H5.0FT Hyster

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
5 t
Centre of gravity
600 mm
Standard tyres
SE 2x/2
Transmission type
W
Weight
7.523 t
Total width
1450 mm
Construction height
2300 mm
Turning radius
2.877 m
Lifting height
4.145 m
Travel speed with / without load
18.1/18.4 km/h
Hoisting with / without load
0.48/0.49 m/s
Lowering with load
0.51/0.42 m/s
max. climbing ability
21.5 %
Model series
H
Engine manuf.
Cummins
Engine type
QSB3.3
Engine power
60 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Hyster H5.0FT overview

Drive

Kubota V3600 Diesel Engine

The Kubota V3600 Diesel engine is only available in territories with category 1 diesel fuel, which contains sulphur levels of over 500ppm. This engine is not compatible with (<500ppm) or Ultra-Low (<15ppm) sulphur diesel fuel.
