D100S-9 Doosan diesel forklift specs & dimensions (2021 - 2026)

The Doosan D100S-9 is a diesel forklift manufactured since 2021. It has a weight of 15.3 tons and a nominal load at the center of …

The Doosan D100S-9 is a diesel forklift manufactured since 2021. It has a weight of 15.3 tons and a nominal load at the center of gravity of 10 tons. The center of gravity is at 600 mm, and it has a maximum climbing ability of 51 percent. The hoisting speed with a load is 0 m/s, and the lowering speed with a load is 0.42 m/s. The total width of the forklift is 2350 mm, and it can travel at a speed of 36 km/h with or without a load. It has a turning radius of 4.255 meters and a construction height of 2950 mm.

Diesel Forklifts Doosan D100S-9

Visit Doosan live at

Technical specs - D100S-9 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
10 t
Centre of gravity
600 mm
Weight
15.3 t
Total width
2350 mm
Construction height
2950 mm
Turning radius
4.255 m
Travel speed with / without load
36/41 km/h
Hoisting with / without load
0.46/0.49 m/s
Lowering with load
0.42/0.41 m/s
max. climbing ability
51 %
Model series
D 9
Engine manuf.
Doosan
Engine type
DL06
Engine power
128.8 kW
Displacement
5.89 l
Revolutions at max torque
2100 rpm
Max. torque
725.7 Nm
No. of cylinders
6
Emission level
V

More technical details, like: standard tyres, transmission type, lifting height, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
