DPL 100 Clark diesel forklift specs & dimensions (1993 - 2003)

The Clark DPL 100 is a diesel forklift manufactured by Clark from 1993 to 2003. It weighs 14.5 tons and has a nominal load capacit…

The Clark DPL 100 is a diesel forklift manufactured by Clark from 1993 to 2003. It weighs 14.5 tons and has a nominal load capacity of 10 tons at the center of gravity, which is located at 1200 mm.

Clark DPL 100 Dimensions and Size

Technical specs - DPL 100 Clark

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
10 t
Centre of gravity
1200 mm
Standard tyres
L 4x/2
Transmission type
W
Weight
14.5 t
Model series
DPL
Engine manuf.
Perkins
Engine type
1006.60T
Engine power
85 kW

More technical details, like: total width, construction height, turning radius, lifting height, travel speed with / without load, hoisting with / without load, lowering with load, max. climbing ability, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: total width, construction height, turning radius, lifting height, travel speed with / without load, hoisting with / without load, lowering with load, max. climbing ability, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)
