Drive
Instrument Panel
An operator display includes hour meter, battery charge, engine oil pressure, check engine light, low LPG, glow transmission temperature, park brake “on,” low water temperature, fuel gauge and transmission oil level. Five LED lights show fuel, engine oil pressure and temperature and park brake status. The analog and electronic instrument panel provides the operator with all necessary information to ensure safe and efficient operation.
Engine Accessories/Capacities
Electrical systems are 12 volt, negative ground, and 50 amp alternator with integral regulator on LPG and 40 amp on diesel engines. Low maintenance battery is rated at 550 cold cranking amps at 0°F (-18°C) on LPG and 800 CCA on diesel engines. The heavy-duty engine air cleaner is easily serviced. An external high-mount air intake with rain cap is provided. Cooling system capacity is 6.7 quarts (6.3 L); engine oil capacity with filter is 4.0 quarts (4.2 L). Fuel tanks on dual fuel or diesel models are 8.9 gals. (33.7 L).
Brakes
Self-energizing, hydraulic-actuated drum and shoe type service brakes. Heavy cast iron brake shoes, backing plates and drums with openings for lining inspection and adjustment. All components are asbestos-free. The brakes are accessed by removing the wheel hub, axleshaft and brake drum. The left and right parking brake pedal actuates service brakes at both drive wheels, while electric transmission interrupt and fingertip release. The transmission is disengaged when the parking brake is applied.
