DP30N3 Caterpillar diesel forklift specs & dimensions (2021 - 2026)

The Caterpillar DP30N3 is a diesel forklift machine manufactured since 2021. It has a weight of 4.43 tons and a nominal load capac…

The Caterpillar DP30N3 is a diesel forklift machine manufactured since 2021. It has a weight of 4.43 tons and a nominal load capacity of 3 tons at the center of gravity. The lifting height of this forklift is 3.3 meters, with a center of gravity at 500 millimeters. It has a maximum climbing ability of 39 percent and a lowering speed of 0.5 meters per second with a load. The total width of the forklift is 1275 millimeters, and it has a turning radius of 2.38 meters. The construction height of the machine is 2165 millimeters.

Diesel Forklifts Caterpillar DP30N3

Technical specs - DP30N3 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3 t
Centre of gravity
500 mm
Standard tyres
Front: 28x9-15-12PR/ Rear: 6.50-10-10PR
Weight
4.43 t
Total width
1275 mm
Construction height
2165 mm
Turning radius
2.38 m
Lifting height
3.3 m
Travel speed with / without load
16/17 km/h
Hoisting with / without load
0.49/0.51 m/s
Lowering with load
0.5 m/s
max. climbing ability
39 %
Model series
DP
Engine manuf.
N/A
Engine type
DO4EG
Engine power
36 kW
Displacement
3.3 l
Revolutions at max torque
1800 rpm
Max. torque
177 Nm
No. of cylinders
4

More technical details, like: transmission type, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download specalog and datasheets (PDF)

Caterpillar DP30N3 overview

Drive

Durable, Consistent, Rugged

Our range of smaller engine-powered trucks offers an excellent blend of power and performance with the advantage of low fuel consumption - for easy and economical use.


Performance

Lower Cost of Ownership

Modern design techniques in combination with long component life result in a long service interval which reduces total cost of ownership. Vehicle Control Module manages various truck and operator functions, allowing easy troubleshooting and pinpointing of problems. LCD display provides extensive information on truck operation, maintenance state and soot level (diesel) - with indication of service requirements to prevent unexpected downtime and costs due to unscheduled servicing and repairs. LED front work lights and front/rear combination lights reduce energy consumption and maintenance costs. Robust and durable chassis is fitted with full belly guard to protect engine compartment from dust, water and dirt.
