Potain MD 155-G 8 crane - load chart, specs (1991 - 1994)

Name: Potain MD 155-G 8 Tower Cranes - Trolley Boom - Top-slewing
Brand: Potain

Manufactured by Potain, this is the MD 155-G 8 tower crane - trolley boom - top-slewing. Find and download detailed specs and data…

Manufactured by Potain, this is the MD 155-G 8 tower crane - trolley boom - top-slewing. Find and download detailed specs and data sheets for this machine here.

The MD 155-G 8 is categorised in the smallest machine segment in the tower crane - trolley boom - top-slewing category. The longest standard boom the Potain MD 155-G 8 can have is 40m. The Potain MD 155-G 8 can carry up to 8t. The Potain MD 155-G 8 crane provides 16.3m reach while carrying the maximum load. The MD 155-G 8 is designed to carry a load of 3.05t at its maximum reach. The rate of nominal torque is 1250. Based on model specifications, the MD 155-G 8 max. Hook height is 37.7m.

Since 1991, this model has included Add. Ballast, Cross girder and Cabin. It has been sold without Rail carrier, Climbing device and Undercarriage as of 1994. Get the original Potain MD 155-G 8 datasheet for even more detailed specifications and machine details.

This model can be acquired for a list price between €243,000 and €309,000. Production of the MD 155-G 8 in 1994.

The MD 155-G 8 Potain can be compared to several models from other manufacturers. The closest tower cranes - trolley boom - top-slewing based on specification and pricing are the Wolff 5520 SL-6, ITK ITK 6015-8 and Wolff 5520 SL-6. Want more detailed specifications? Download the latest Potain MD 155-G 8 specs data sheet on LECTURA Specs today!

MD 155-G 8

Years of manufacture: 1991—1994

Buy & Rent
Spare parts
Transport
Events & News

Technical specs - MD 155-G 8 Potain

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque: 1250 kNm

Max. load: 8 t

Load at max. Reach: 3.05 t

Reach at max. Load: 16.3 m

max. standard boom: 40 m

max. hook height: 37.7 m

Tower system: ZD 46 A

Connection load: 80 KVA

Model series: MD

More technical details, like: ropes, max. reach, max. luffing jib, min. luffing jib, tower height, max. hoisting speed, drive system, hoist unit are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: Yes
Add. ballast: Yes
Rail carrier: No
Climbing device: No
Undercarriage: No
Cross girder: Yes

Machine inspection

Ask for inspection of your Potain MD 155-G 8 from experts

Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.

Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.

Enquire machine inspection

Provided by:

Buy & Rent

Compare Potain MD 155-G 8 with similar Tower Cranes - Trolley Boom - Top-slewing

Potain MD 155-G 8

Nominal torque:: 1250 kNm

Max. load:: 8 t

Load at max. Reach:: 3.05 t

Reach at max. Load:: 16.3 m

Terex Comedil (Zeppelin) CTT 91

Nominal torque:: 1050 kNm

Max. load:: 5 t

Load at max. Reach:: 2.2 t

Reach at max. Load:: 19.6 m

Wilbert WT 150 e.tronic

Nominal torque:: 1500 kNm

Max. load:: 6 t

Load at max. Reach:: 2 t

Reach at max. Load:: 24.4 m

Condecta SSG 120

Nominal torque:: 1184 kNm

Max. load:: 8 t

Load at max. Reach:: 1.5 t

Reach at max. Load:: 14 m

ITK ITK 6612-8

Nominal torque:: 1050 kNm

Max. load:: 8 t

Load at max. Reach:: 1.2 t

Reach at max. Load:: 14.7 m
