SSG 120 Condecta crane - load chart, specs & dimensions (2007 - 2008)

Condecta is the manufacturer of the tower crane - trolley boom - top-slewing model SSG 120. Find and download detailed specs and d…

Condecta is the manufacturer of the tower crane - trolley boom - top-slewing model SSG 120. Find and download detailed specs and data sheets for this machine here.

The SSG 120 is categorised in the smallest machine segment in the tower crane - trolley boom - top-slewing category. The main boom in its maximum length measures 60m. The carrying capacity of this Tower crane - Trolley boom - top-slewing is 8t. 14m is the reach of SSG 120 when lifting the maximum load. The datasheet for SSG 120 indicates that this model can carry a 1.5t load at max. Reach. As stated in model specifications, the nominal torque is 1184. The max. Hook height is 50.8m.

The SSG 120 is manufactured and distributed with Add. Ballast, Cross girder and Cabin. It does not include Rail carrier, Climbing device and Undercarriage. Get the original Condecta SSG 120 datasheet for even more detailed specifications and machine details. Specification sheet is available for a free download in German, French, Italian and English - providing the machine descriptions and more detailed specs about this particular model.

The production in 2008, where this SSG 120 was available at a new list price between €272,000 and €346,000.

The SSG 120 Condecta can be compared to several models from other manufacturers. The closest tower cranes - trolley boom - top-slewing based on specification and pricing are the Terex Peiner SK 136-F-TS 18.2, Zeppelin ZBK 125-FK46-TS16 and Zeppelin ZBK 140-TS16-FK46. Want more detailed specifications? Download the latest Condecta SSG 120 specs data sheet on LECTURA Specs today!

Tower Cranes - Trolley Boom - Top-slewing Condecta SSG 120

Technical specs - SSG 120 Condecta

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque
1184 kNm
Max. load
8 t
Load at max. Reach
1.5 t
Reach at max. Load
14 m
max. standard boom
60 m
max. hook height
50.8 m
Connection load
45 KVA
Model series
SSG

More technical details, like: max. reach, max. luffing jib, min. luffing jib, tower height, ropes, max. hoisting speed, tower system, drive system, hoist unit are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
Yes
Add. ballast
Yes
Rail carrier
No
Climbing device
No
Undercarriage
No
Cross girder
Yes
