Lectura specs Cranes Tower Cranes - Trolley Boom - Top-slewing Tower Cranes - Trolley Boom - Top-slewing Jaso Jaso J85 specifications

Jaso J85 crane - load chart, specs (2017 - 2024)

Rate this machine now!

Max. load: 6t – max. reach: 55m – Load at max. Reach: 1.4t – Reach at max. Load: 25m – max. standard boom: 55m – min. luffing jib:... Read more

Max. load: 6t – max. reach: 55m – Load at max. Reach: 1.4t – Reach at max. Load: 25m – max. standard boom: 55m – min. luffing jib: 25m

See load chart, specs, capacity, size and other technical data for Jaso J85 crane manufactured between 2017 - 2024. See information, like: Max. load: 6t – max. reach: 55m – Load at max. Reach: 1.4t – Reach at max. Load: 25m – max. standard boom: 55m – min. luffing jib: 25m and more.

Technical specs - J85 Jaso

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Max. load 6 t
  • max. reach 55 m
  • Load at max. Reach 1.4 t
  • Reach at max. Load 25 m
  • max. standard boom 55 m
  • min. luffing jib 25 m
  • Tower height 57.9 m
  • max. hook height 47.7 m
  • Ropes 2
  • max. hoisting speed 60 m/min
  • Drive system E
  • Hoist unit 24.2 kW

More technical details, like: nominal torque, max. luffing jib, tower system, connection load, model series are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

  • Cabin
  • Add. ballast
  • Rail carrier
  • Climbing device
  • Undercarriage
  • Cross girder
