21CM650 Comansa crane - load chart, specs & dimensions (2020 - 2023)

Max. load: 20t – max. reach: 80m – Load at max. Reach: 4.95t – Reach at max. Load: 30.8m – max. standard boom: 80m – min. luffing …

Max. load: 20t – max. reach: 80m – Load at max. Reach: 4.95t – Reach at max. Load: 30.8m – max. standard boom: 80m – min. luffing jib: 30m

See load chart, specs, capacity, size and other technical data for Comansa 21CM650 crane manufactured between 2020 - 2023. See information, like: Max. load: 20t – max. reach: 80m – Load at max. Reach: 4.95t – Reach at max. Load: 30.8m – max. standard boom: 80m – min. luffing jib: 30m and more.

Tower Cranes - Trolley Boom - Top-slewing Comansa 21CM650

Technical specs - 21CM650 Comansa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Max. load
20 t
max. reach
80 m
Load at max. Reach
4.95 t
Reach at max. Load
30.8 m
max. standard boom
80 m
min. luffing jib
30 m
Tower height
93.3 m
max. hook height
87.9 m
max. hoisting speed
131 m/min
Drive system
HFU4-80-62
Connection load
110 KVA
Hoist unit
80 kW
Model series
LC2100

More technical details, like: nominal torque, max. luffing jib, ropes, tower system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin
Yes
Add. ballast
Yes
Rail carrier
Yes
Climbing device
Yes
Undercarriage
Yes
Cross girder
Yes

Download datasheets (PDF)

Comansa 21CM650 overview

Work

LC2100 series

In the 70s, the launch of the LINDEN 8000 modular series introduced to the market a new focus in the world of cranes. This ingenious concept allows the installation of cranes with different loading capacities using the same standard system, providing up to now inconceivable flexibility. LINDEN COMANSA has since developed the Flat-Top modular system, applying it to its entire range of tower cranes, which includes the LC2100 series. This family of cranes is currently made up of five models between 335 and 750 metric tons, with different versions according to their maximum load. These are high-capacity load cranes (from 12 to 48 tons / 26,450 to 105,820 lb), highly efficient for any type of construction, particularly mining, infrastructure, industry and civil engineering works.


Tower

Special applications

Based on the standard designs, LINDEN COMANSA also deals with increasingly specific requests, designing developments for special applications: the jibs for the partial disassembly of the jib and counterweights, vital in the construction of hyperbolic cooling towers. Additionally, the incorporation of electrical connection points at crane hook level for handling auxiliary gear are just some of the examples of essential applications in the LC2100 series.
