Condecta E 3210 L-R 2,2 m crane - load chart, specs (2003 - 2006)

Name: Condecta E 3210 L-R 2,2 m Tower Cranes - Trolley Boom - Bottom-slewing
Brand: Condecta

Nominal torque: 355kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 10.61m – max. standard boom: 32m – max. hook…

Nominal torque: 355kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 10.61m – max. standard boom: 32m – max. hook height: 20m

See load chart, specs, capacity, size and other technical data for Condecta E 3210 L-R 2,2 m crane manufactured between 2003 - 2006. See information, like: Nominal torque: 355kNm – Max. load: 4t – Load at max. Reach: 1t – Reach at max. Load: 10.61m – max. standard boom: 32m – max. hook height: 20m and more.

E 3210 L-R 2,2 m

Years of manufacture: 2003—2006

Buy & Rent
Spare parts
Transport
Events & News

Technical specs - E 3210 L-R 2,2 m Condecta

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal torque: 355 kNm

Max. load: 4 t

Load at max. Reach: 1 t

Reach at max. Load: 10.61 m

max. standard boom: 32 m

max. hook height: 20 m

Connection load: 20 KVA

Hoist unit: 9 kW

Model series: E

More technical details, like: ropes, max. reach, max. luffing jib, min. luffing jib, tower height, max. hoisting speed, tower system, drive system are available in the full technical specs.

If alignment change (2/4) is possible, the loads for quadruple alignment applies. In case of crane on anchor bolt, the anchor is not included in base price. Incl. concrete ballast, crane control and spindles with plates (latter not valid with rail-bound travelling, incl. cable drum and cruciform base)

Special equipment

Cabin: Yes
Rail carrier: No
Road Carrige: No
Steep jib pos.: Yes
Hot-dipped galvanised: Yes
Ballasting device: No
