6010LP Tadano crane - load chart, specs & dimensions (2021 - 2026)

max. carrying capacity: 27t – at reach: 3m – Carrying capacity: 3.084t – at max. reach: 24.384m – max. standard boom: 24.4m – Min.…

max. carrying capacity: 27t – at reach: 3m – Carrying capacity: 3.084t – at max. reach: 24.384m – max. standard boom: 24.4m – Min. standard boom: 9.9m

See load chart, specs, capacity, size and other technical data for Tadano 6010LP crane manufactured between 2021 - 2026. See information, like: max. carrying capacity: 27t – at reach: 3m – Carrying capacity: 3.084t – at max. reach: 24.384m – max. standard boom: 24.4m – Min. standard boom: 9.9m and more.

Crawler cranes - Telescopic boom Tadano 6010LP

Technical specs - 6010LP Tadano

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

max. carrying capacity
27 t
at reach
3 m
Carrying capacity
3.084 t
at max. reach
24.384 m
max. standard boom
24.4 m
Min. standard boom
9.9 m
Max. luffing jib
12,192 m
Engine power
129 kW
Travel speed
4.2 km/h
Model series
LP

More technical details, like: max. hook height, add. ballast, load torque, soil pressure, engine manuf., engine type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke...

More technical details, like: max. hook height, add. ballast, load torque, soil pressure, engine manuf., engine type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, weight, emission level are available in the full technical specs.

Including hook block

Special equipment

2nd winch
Yes
max. luffing jib
Yes
Add. ballast
No
