655E Sennebogen crane - load chart, specs & dimensions (2022 - 2026)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Sennebogen live at
Technical specs - 655E Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- max. carrying capacity
- 55 t
- at reach
- 2.7 m
- Carrying capacity
- 1 t
- at max. reach
- 40.7 m
- max. standard boom
- 49.5 m
- Min. standard boom
- 10.3 m
- Max. luffing jib
- 18 m
- Engine power
- 283 kW
- Travel speed
- 2 km/h
- Model series
- E
- Engine manuf.
- Cummins
- Engine type
- L9
- Emission level
- Stage V
More technical details, like: max. hook height, load torque, soil pressure, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, weight are available in the full technical specs.
Including hook block
Special equipment
- 2nd winch
-
No
- Add. ballast
-
No
- Basic boom
-
Yes
- Tip extension
-
No
