2200E Sennebogen crane - load chart, specs & dimensions (2021 - 2022)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Sennebogen live at
Technical specs - 2200E Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- max. carrying capacity
- 80 t
- at reach
- 4 m
- Carrying capacity
- 0.6 t
- at max. reach
- 50.9 m
- max. standard boom
- 59.7 m
- Min. standard boom
- 12.1 m
- Max. luffing jib
- 24.3 m
- max. hook height
- 59.7 m
- Engine power
- 186 kW
- Travel speed
- 1.9 km/h
- Model series
- E
- Engine manuf.
- Caterpillar
- Engine type
- C7.1
- Emission level
- Tier IIIb
More technical details, like: load torque, soil pressure, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, weight are available in the full technical specs.
Including hook block
Special equipment
- 2nd winch
-
No
- Add. ballast
-
No
- Basic boom
-
No
- Tip extension
-
No
