Liebherr LTM 1050-3.1 crane - load chart, specs (2008 - 2020)

Name: Liebherr LTM 1050-3.1 All-terrain Cranes
Brand: Liebherr
Rating: 9,40 (5 reviews)

9,40/10 Rate this machine now!

max. carrying capacity: 50t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 44m – max. standard boom: 38m – Min. standar... Read more

max. carrying capacity: 50t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 44m – max. standard boom: 38m – Min. standard boom: 11.4m

See load chart, specs, capacity, size and other technical data for Liebherr LTM 1050-3.1 crane manufactured between 2008 - 2020. See information, like: max. carrying capacity: 50t – at reach: 3m – Carrying capacity: 0.6t – at max. reach: 44m – max. standard boom: 38m – Min. standard boom: 11.4m and more.

Read less

Technical specs
Buy & Rent
Parts & Components
Events & News
Transport
Contacts & Help
Machine inspection

Technical specs - LTM 1050-3.1 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

max. carrying capacity 50 t
at reach 3 m
Carrying capacity 0.6 t
at max. reach 44 m
max. standard boom 38 m
Min. standard boom 11.4 m
Max. luffing jib 16 m
max. hook height 54 m
Load Torque 1760 kNm
Undercarriage engine 270 kW
Travel speed 80 km/h
Number of axles 3
Wheels/Drive/Steering 6/4/6
Standard tyres 385/95 r25
Outriggers spacing length 7.151 m
Outriggers spacing width 6.4 m
Engine manuf. Liebherr
Engine type N/A
Engine power 270 kW
Max. torque 1720 Nm
No. of cylinders 6
Emission level EPA

More technical details, like: superstructure engine, axle load, tipping load, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke, weight are available in the full technical specs.

Including hook block

Special equipment

2nd winch
max. luffing jib
max. fold hydr.
Erection tip
Foucault current brake
Add. ballast
