Lectura specs Construction machinery Wheeled Asphalt Pavers Wheeled Asphalt Pavers Terex Terex CR352L specifications

Terex CR352L Specifications & Technical Data (2008-2023)

Rate this machine now!

Weight: 13.046t – Transport length: 5.436m – Transport width: 3.05m – Transport height: 2.642m – Standard width: 2.44m – Max. width: 6.1m

Technical specs - CR352L Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 13.046 t
  • Transport length 5.436 m
  • Transport width 3.05 m
  • Transport height 2.642 m
  • Standard width 2.44 m
  • Max. width 6.1 m
  • Drive DE
  • Wheels 18.4x26 10PLY
  • Bunker capacity 4.67 m³
  • Operating speed 122 m/min
  • Type of screed V
  • Engine manuf. Cummins
  • Engine type QSB4.5
  • Engine power 119 kW
  • Revolutions at max torque 2200 rpm

More technical details, like: average fuel consumption, fuel consumption range (min - max), hydr. extension from, hydr. extension up to, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

  • Diesel particulate filter
  • Bilateral levelling automatic
  • Vibration
  • High compaction
  • Spray unit
  • Tamper
