IR-ABG Titan 6870 Specifications & Technical Data (2007-2007)

Technical specs - Titan 6870 IR-ABG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 17.5 t

Standard width: 2.5 m

Max. width: 9 m

Hydr. extension from: 2.5 m

Hydr. extension up to: 5 m

Drive: DH

Operating speed: 40 m/min

Model series: Titan

Engine manuf.: Deutz

Engine type: TCD2013 L04

Engine power: 122 kW

Emission level: III B

More technical details, like: transport length, transport width, transport height, wheels, bunker capacity, type of screed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: Yes
High compaction: No
Spray unit: No
Tamper: Yes

IR-ABG Titan 6870 FAQ

When was the IR-ABG Titan 6870 manufactured?

The IR-ABG Titan 6870 was manufactured in 2007.

How much does the IR-ABG Titan 6870 weigh?

The IR-ABG Titan 6870 weighs 17.5 tons.

What is the operating speed of the IR-ABG Titan 6870 wheeled asphalt paver?

The IR-ABG Titan 6870 has an operating speed of 40 meters per minute.

What type of drive system does the IR-ABG Titan 6870 have in its undercarriage?

The IR-ABG Titan 6870 has a diesel hydraulic drive system in its undercarriage.

What are the paving performance specifications of the IR-ABG Titan 6870?

The IR-ABG Titan 6870 has a standard paving width of 2.5 meters, can extend hydraulically from 2.5 up to 5 meters, achieves a maximum paving width of 9 meters, and operates at a speed of 40 meters per minute.
