AP600D Caterpillar AP600D Specifications & Technical Data (2010—2016)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - AP600D Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 18.2 t
- Transport length
- 6.2 m
- Transport width
- 3 m
- Transport height
- 3.8 m
- Standard width
- 2.55 m
- Max. width
- 5 m
- Hydr. extension up to
- 8 m
- Drive
- DH
- Bunker capacity
- 6.5 m³
- Operating speed
- 25 m/min
- Type of screed
- V/T
- Model series
- AP
- Engine manuf.
- Caterpillar
- Engine type
- C6.6 Acert
- Engine power
- 129.5 kW
- Displacement
- 6.6 l
- Emission level
- Tier 4 f
More technical details, like: hydr. extension from, wheels, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention
Special equipment
- Diesel particulate filter
-
No
- Bilateral levelling automatic
-
No
- Vibration
-
No
- High compaction
-
No
- Spray unit
-
No
- Tamper
-
No
Download specalog and datasheets (PDF)
