AR 75 e T weycor AR 75 e T Specifications & Technical Data (2016—2019)

The Weycor AR 75 e T is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 6 tons and a transport length …

The Weycor AR 75 e T is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 6 tons and a transport length of 5.8 meters. The bucket capacity is 1 cubic meter with a width of 2.15 meters. The maximum discharge height is 4.08 meters. It has a travel speed of 20 km/h and a transport width of 1.95 meters. The transport height is 2.8 meters. The lifting force is 36 kN. The turning radius outside is 5.15 meters. It is equipped with special features such as quick hitch hydr., quick hitch mech., and telescopic capabilities.

Visit weycor live at

AR 75 e T

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - AR 75 e T weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6 t

Standard tyres: 16/70

Bucket width: 2.15 m

Bucket capacity: 1 m³

Bucket capacity min.: 1 m³

Steering mode: KL

Transport length: 5.8 m

Transport width: 1.95 m

Transport height: 2.8 m

Travel speed: 20 km/h

Max. discharge height: 4.08 m

Turning radius outside: 5.15 m

Lifting force: 36 kN

Model series: AR

Engine manuf.: Deutz

Engine type: TD2.9 L04

Engine power: 54 kW

Displacement: 2.92 l

Revolutions at max torque: 1800 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: Yes

Download datasheets (PDF)

weycor AR 75 e T FAQ

When was the weycor AR 75 e T manufactured?

The weycor AR 75 e T was manufactured from 2016 to 2019.

How much does the Weycor AR 75 e T weigh?

The Weycor AR 75 e T weighs 6 tons.

What are the transport dimensions of the weycor AR 75 e T wheel loader?

The weycor AR 75 e T has a transport length of 5.8 meters, a transport width of 1.95 meters, and a transport height of 2.8 meters.

What is the travel speed of the weycor AR 75 e T wheel loader?

The weycor AR 75 e T wheel loader has a travel speed of 20 km/h.

What is the standard tyre size of the weycor AR 75 e T wheel loader?

The weycor AR 75 e T wheel loader has standard tyres of size 16/70.

What are the maneuverability specifications of the weycor AR 75 e T wheel loader?

The weycor AR 75 e T wheel loader has an articulated-frame steering mode and an outside turning radius of 5.15 meters.

What is the lifting force of the weycor AR 75 e T?

The weycor AR 75 e T has a lifting force of 36 kN.

What is the maximum discharge height of the weycor AR 75 e T wheel loader?

The weycor AR 75 e T wheel loader has a maximum discharge height of 4.08 meters.

What are the specifications of the bucket on the weycor AR 75 e T wheel loader?

The bucket of the weycor AR 75 e T has a capacity of 1 cubic meter, a minimum capacity of 1 cubic meter, and a width of 2.15 meters.

How much is a weycor AR 75 e T Wheel loader (2016u20132019) worth?

The residual value of the weycor AR 75 e T depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
