AR 60 e weycor AR 60 e Specifications & Technical Data (2016—2019)

The Weycor AR 60 e is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 4.7 tons and a transport length …

The Weycor AR 60 e is a wheel loader manufactured by Weycor from 2016 to 2019. It has a weight of 4.7 tons and a transport length of 5.25 meters. The bucket capacity is 0.8 cubic meters with a width of 1.9 meters. The maximum discharge height is 2.48 meters. It has a travel speed of 20 km/h and a transport width of 1.79 meters. The transport height is also 2.48 meters. The lifting force is 47 kN and the turning radius outside is 3.69 meters. It is equipped with a diesel particulate filter and a quick hitch hydr.

Visit weycor live at

AR 60 e

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - AR 60 e weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.7 t

Standard tyres: 12.5-18 MPT

Bucket width: 1.9 m

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Steering mode: KL

Transport length: 5.25 m

Transport width: 1.79 m

Transport height: 2.48 m

Travel speed: 20 km/h

Max. discharge height: 2.48 m

Turning radius outside: 3.69 m

Lifting force: 47 kN

Model series: AR

Engine manuf.: Yanmar

Engine type: 4TNV88CHT-M

Engine power: 48.5 kW

Displacement: 2.1 l

Revolutions at max torque: 1690 rpm

More technical details, like: bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

AR 60 e weycor Specification for Europe (EN)

weycor AR 60 e FAQ

When was the weycor AR 60 e manufactured?

The weycor AR 60 e was manufactured from 2016 to 2019.

How much does the weycor AR 60 e weigh?

The weycor AR 60 e weighs 4.7 tons.

What are the transport dimensions of the weycor AR 60 e wheel loader?

The transport dimensions of the weycor AR 60 e are 5.25 meters in length, 1.79 meters in width, and 2.48 meters in height.

What is the travel speed of the weycor AR 60 e wheel loader?

The weycor AR 60 e has a travel speed of 20 km/h.

What are the undercarriage specifications of the Weycor AR 60 e wheel loader?

The Weycor AR 60 e wheel loader is equipped with standard tyres sized 12.5-18 MPT.

What are the maneuverability specifications of the weycor AR 60 e wheel loader?

The weycor AR 60 e wheel loader has an articulated-frame steering mode and a turning radius outside of 3.69 meters.

What is the lifting force rating of the weycor AR 60 e wheel loader?

The weycor AR 60 e wheel loader has a lifting force rating of 47 kN.

What is the maximum discharge height of the Weycor AR 60 e?

The Weycor AR 60 e has a maximum discharge height of 2.48 meters.

What are the specifications of the bucket on the weycor AR 60 e wheel loader?

The bucket of the weycor AR 60 e has a capacity of 0.8 cubic meters and a width of 1.9 meters.

How much is a weycor AR 60 e Wheel loader (2016u20132019) worth?

The residual value of the weycor AR 60 e depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
