AR 580 weycor AR 580 Specifications & Technical Data (2019—2026)

The Weycor AR 580 is a wheel loader manufactured since 2019. It has a weight of 9.6 tons and a transport length of 6.4 meters. The…

The Weycor AR 580 is a wheel loader manufactured since 2019. It has a weight of 9.6 tons and a transport length of 6.4 meters. The bucket capacity is 1.8 cubic meters, with a bucket width of 2.3 meters. The maximum discharge height is 2.93 meters. It has a travel speed of 20 km/h and a transport width of 2.23 meters. The transport height is 2.99 meters. The lifting force is 82 kN, and the turning radius outside is 4.85 meters. The machine is equipped with a diesel particulate filter and a quick hitch hydr. The bucket capacity ranges from a minimum of 1.8 cubic meters to a maximum of 2.3 cubic meters.

Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580
Wheel Loaders weycor AR 580

Visit weycor live at

Technical specs - AR 580 weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
9.6 t
Standard tyres
17.5-25 EM
Bucket width
2.3 m
Bucket capacity
1.8 m³
Bucket capacity min.
1.8 m³
Bucket capacity max.
2.3 m³
Steering mode
KL
Transport length
6.4 m
Transport width
2.23 m
Transport height
2.99 m
Travel speed
20 km/h
Max. discharge height
2.93 m
Turning radius outside
4.85 m
Lifting force
82 kN
Model series
AR
Engine manuf.
Deutz
Engine type
TCD3.6 L04
Engine power
100 kW
Displacement
4.04 l
Revolutions at max torque
1600 rpm
No. of cylinders
4

More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
Yes
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

weycor AR 580 FAQ

When was the weycor AR 580 manufactured?

The weycor AR 580 was first produced in 2019.

How much does the weycor AR 580 wheel loader weigh?

The weycor AR 580 wheel loader weighs 9.6 tons.

What are the transport dimensions of the weycor AR 580 wheel loader?

The weycor AR 580 has a transport length of 6.4 meters, a transport width of 2.23 meters, and a transport height of 2.99 meters.

What is the travel speed of the weycor AR 580 wheel loader?

The travel speed of the weycor AR 580 wheel loader is 20 km/h.

What are the undercarriage specifications of the Weycor AR 580 wheel loader?

The Weycor AR 580 wheel loader is equipped with standard tyres sized 17.5-25 EM.

What are the maneuverability specifications of the weycor AR 580 wheel loader?

The weycor AR 580 wheel loader has an articulated-frame steering system and an outside turning radius of 4.85 meters.

What is the lifting force of the weycor AR 580 wheel loader?

The weycor AR 580 wheel loader has a lifting force of 82 kN.

What is the material handling capacity of the weycor AR 580 in terms of discharge height?

The weycor AR 580 has a maximum discharge height of 2.93 meters.

What are the specifications of the bucket on the weycor AR 580 wheel loader?

The bucket on the weycor AR 580 has a capacity ranging from 1.8 to 2.3 cubic meters and a width of 2.3 meters.
